Series Vents TT PRO

Series Vents TT PRO - Mixed Flow - Inline Fans
TURBO TUBE PRO series is the NEW IDEAL ENGINEERING SOLUTION for premises where powerful, yet quiet airflow is required
  • Motor type: AC
  • Impeller type: Mixed
TURBO TUBE PRO series is the NEW IDEAL ENGINEERING SOLUTION for premises where powerful, airflow is required.

The combination of a UNIQUE MOTOR, POWERFUL MIXED FLOW IMPELLER and SPECIAL AERODYNAMIC CASE enables the TURBO TUBE PRO fans to deliver SUPERB AIRFLOW PERFORMANCE even at HIGHER STATIC PRESSURE typically found in extensive ventilation systems.
Benefits
  • HIGH PERFORMANCE: up to 378 CFM
  • ENERGY EFFICIENT: 38 – 81 W
  • DUCT COMPATIBILITY: Ø 4”, 5”, 6”
  • HIGH PRESSURE
  • DOUBLE-SPEED CAPACITOR MOTOR WITH THERMAL OVERLOAD PROTECTION
  • LONG-LIFE BALL BEARING (up to 40 000 hours)
  • VIBRATION FREE OPERATION
  • BUILT-IN 2-SPEED SWITCH & POWER CORD INCLUDED
  • ROTARY AND REMOVABLE CENTRAL “BODY” FOR EASY INSTALLATION & MAINTENANCE
  • COMPACT SIZE FOR LIMITED SPACES
  • LIGHTWEIGHT, DURABLE AND UV RESISTANT PLASTIC CASE (FLAME RATING – 5VA)
  • CORROSION FREE
Innovative design

AERODYNAMIC CASE. The unique motor and special aerodynamic case combination enables the fans to deliver superb airflow performance even at higher static pressure

NEWLY DESIGNED IMPELLER. The newly designed impeller, due to the specifically changed angle of inclination, provides the most powerful airflow at any pressure in ventilation systems

EASY TO INSTALL & CLEAN. The Removable Body, including motor, impeller and junction box, is the Ultimate Solution for Easy Installation & cleaning

EASY CONNECTION. The Removable Body with the junction box can be rotated 180° to Facilitate Mounting and Wiring

BUILT-IN SPEED CONTROL. The Double-speed Motor is controlled with a Built-in Speed Switch

INTEGRATED MOUNTING BRACKET. The fan case is Equipped with a Mounting Plate to attach the fan to the wall or ceiling

Easy installation

Fix the fan mounting plate on the flat surface

Install the removable body inside the fan case

Lock the removable body by clamps with latches

Secure latches by screws

Attach the ducts with clamps

Insert the plug into electrical socket - the fan is READY to GO!

Select a required speed by the built-in speed switch. ENJOY the FRESH AIR

Forget about dismantling! Just remove the central body from the case and complete the servicing!

Lineup Vents TT PRO Connected air duct size, in Rated power, W Maximum performance @0.1", CFM
48 206
62 285
81 372
